Type = Nickel
Type Formula = Y 7 LER 02
Heat Range = 7
Spanner Size = 16
Thread Length (mm) = 19
Thread Diameter (mm) = 12
Thread Pitch (mm) = 1.25
Centre Electrode Connection Material = NiY+Cu
Centre Electrode Material = NiY
Ground Electrode Material = NiY+Cu
Spark Position (mm) = 5
Gap (mm) = 1.0
Center Electrode ( mm ) = 2.3
NO. Poles = 1
Resistance (Kohm) = 1
Tightning Angle = 90
Tightening Torque (N.m) = 23
Type of Connection = Cup
